GEFRAN MN1-6-M-B05C-1-4-D Melt pressure transmitter 0~10V in stock

Introduction

The MN series of Gefran, are pressure transmitters for using in High temperature environment.The main characteristic of this series is the capability to read temperature of the media up to 400°C.The constructive principle is based on the hydraulic transmission of the pressure.The fluid-filled system assures the temperature stability.The phisical measure is transformed in a electrical measure by means the strain-gauge technology.

Features

Pressure ranges from:
0-35 to 0-2000 bar / 0-500 to 0-30000 psi
• Accuracy: < ±0.25% FSO (H); < ±0.5% FSO (M)
• Fluid-filled system for temperature stability
• Mercury filling volume:
MN0 (30mm 3 ); MN1, MN2, MN3 (40mm 3 )
• 1/2-20UNF, M18x1.5 standard threads; other types available on request
• Other diaphragms available on request
• Autozero function on board / external option
• Drift Autocompensation function (SP version)
• Standard diaphragm is 15-5 PH stainless steel with GTP+ coating
• 17-7 PH corrugated diaphragm with GTP+ coating for ranges below 100 bar-1500 psi
GTP+ (advanced protection)
Coating with high resistance against corrosion, abrasion and high temperature
